Charvel Pro-Mod DK24 HH FR Mahogany with Quilt Maple Electric Guitar. Maple FB, Dark Amber

Loaded with premium features, this DK24 model has a sleek Dinky® body constructed from mahogany with an exquisite quilt maple top finished in Dark Amber with satin gold hardware. The sculpted shredder's cut heel and scalloped lower back bout make access to the upper registers seamless, while the bolt-on maple neck features graphite reinforcement for rock-solid stability. The silky-smooth hand-rubbed satin urethane finish on the back of the neck grants sublime playability, while the conveniently located heel-mount truss rod adjustment wheel makes for painless neck relief tweaks. Designed for speed, the 12"-16" compound radius maple fingerboard features comfortable rolled edges, 24 jumbo frets and offset black dot inlays.



Under the hood, the DK24 is ready to handle your heaviest riffs, tastiest leads or angelic clean tones with a Seymour Duncan® Full Shred™ bridge pickup and Seymour Duncan Alnico II™ Pro APH-1N neck pickup. Dial in the tonal spectrum that best suits playing with five-way blade switching, volume control (with 500K EVH® Bourns™ low friction potentiometer) and a no-load tone control that operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound that lets the full natural voice of the guitar shine through.



The Pro-Mod DK24 HH FR M Mahogany with Quilt Maple is also equipped with a recessed Floyd Rose® 1000 Series double-locking tremolo bridge system, providing super tuning stability with radical pitch-raising capability.



Specifications:



- Series: Pro-Mod

- Orientation: Right-Hand

- Color: Dark Amber

- Country of Origin: Mexico



- Headstock: Licensed Fender® Stratocaster®

- Neck Material: Maple

- Neck Finish: Hand-Rubbed Satin Urethane

- Neck Shape: Speed Neck with Rolled Fingerboard Edges

- Neck Construction: Bolt-On with Graphite Reinforcement

- Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)

- Fingerboard Material: Maple

- Position Inlays: Offset Black Dot

- Number of Frets: 24

- Truss Rod: Dual-Action with Wheel

- Truss Rod Nut: Heel-Mount Truss Rod Adjustment Wheel

- String Nut: Floyd Rose® 1000 Series Locking

- Nut Width: 1.6875" (42.86 mm)



- Body Material: Mahogany

- Body Finish: Gloss

- Body Shape: Dinky®

- Body Top: Quilt Maple

- Body Style: Solid Body



- Bridge: Floyd Rose® 1000 Series Double-Locking Tremolo (Recessed)

- Pickguard: None

- Pickup Covers: White

- Control Knobs: Dome-Style

- Switch Tip: White

- Hardware Finish: Satin Gold

- Tuning Machines: Charvel®-Branded Die-Cast

- String Trees: Floyd Rose® Retainer Bar

- Strings: Nickel Plated Steel (.009-.042 Gauges)

- Tremolo Arm: Floyd Rose® 1000 Series Locking

- Neck Plate: None - 4-Bolt Sculpted Heel

- Strap Buttons: Standard



- Bridge Pickup: Seymour Duncan® Full Shred™ SH-10B

- Neck Pickup: Seymour Duncan® Alnico II Pro™ APH-1N

- Pickup Configuration: HH

- Controls: Volume (500K EVH® Bourns® Low Friction Pot), No-Load Tone



Switching:

- Position 1: Full Bridge Pickup

- Position 2: Bridge Inner Coil

- Position 3: Both Inner Coils

- Position 4: Neck Inner Coil

- Position 5: Full Neck Pickup



- Dimensions: 4.40 x 15.30 x 42.30 IN

- Shipping Weight: 11.25 LB

- Fret Size: Jumbo

- Scale Length: 25.5" (64.77 cm)

- Shipping Length: 42.30 IN

- Shipping Height: 4.40 IN

- Shipping Width: 15.30 IN



- Saddle Height Wrench: Yes
