EVH SA-126 Special Electric Guitar. QM, Transparent Purple

In 2024, we will once again challenge the “norm” with the introduction of the SA-126 Special, Wolfgang Van Halen’s interpretation of what a modern guitar should be in the 21st century.

SA-126 is the very definition of innovation incarnate. It’s a hybrid between semi-hollow and solid body guitar: think chambered/center block solid body blended with a bolt-on neck, then kitted out with features most frequently associated with high performance guitar brands such as a slim neck, jumbo frets and higher output pickups. The brain child of Wolfgang Van Halen, the instrument was created with versatility in mind, striking the perfect balance between pummeling rhythm tones and lightning-fast lead runs.

Here is a quick look at the features

• 24.75" scale length
• Chambered mahogany body with a basswood centerblock
• Graphite-reinforced bolt-on mahogany neck w/ a satin natural finish
• 12"-16" compound radius ebony fingerboard with 22 jumbo frets and dot inlay
• Convenient heel-mount truss rod adjustment spoke wheel
• Direct Mount EVH® SA-126 bridge and neck humbucking pickups
• Harmonica bridge with stoptail piece
• Three-way toggle switch, two volumes and two tones
• Available in Tobacco Burst with gold hardware and Transparent Purple
• SA-126 Ivory wrapped with crushed blue velvet interior case, included

The all-new SA-126 features a Mahogany body that is chambered, with a basswood Centerblock added for stability and tone. Capped with a maple top on solid finishes and quilt maple on transparent finishes w/ 5 ply body binding, this thing emits “TONE”. The neck is a 22 fret 12”-16” compound Ebony fingerboard with jumbo frets and triple block inlays on a graphite reinforced mahogany neck. With a scale length of 24 and three quarters… this feels like a modern - classic that is familiar and comfortable. Finally, a spoke wheel truss rod adjustment at the butt end of the neck for easy adjustments, on the fly.

Introducing the EVH SA-126 bridge and neck pickups created by Fender’s resident pickup designer Tim Shaw and the EVH team, they can handle just about anything you feed them. From the elegant sound of cascading-glassy cleans to a heavy bath of Overdrive to “Burn” that will satisfy the most discerning gainiac. Three-way toggle at the upper horn to switch between bridge, bridge and neck, and neck pickups as well as two volumes and two tones to control each. Other features include a Harmonica bridge and stop bar tailpiece, oversized strap buttons, and keystone tuning pegs.

The SA-126 Special comes in 4 finishes. Tobacco Sunburst w/ Gold Hardware, Transparent Purple w/ Chrome Hardware, and Matte Army Drab as well as Stealth Black w/ Black hardware. Finally, this also comes with the SA126 Hardshell case that is wrapped in Ivory vinyl and has blue crushed velvet interior.

Specifications:

General
- Series: SA
- Orientation: Right-Hand
- Color: Transparent Purple
- Country Of Origin: MX
- Platform: EVH® Electric Guitars

Neck
- Headstock Binding: 1-Ply Cream
- Neck Material: 2-Piece Mahogany
- Neck Finish: Natural Satin
- Neck Shape: EVH® Modified "C" Backshape
- Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
- Fingerboard Material: Ebony
- Position Inlays: Triple Block
- Side Dots: White
- Number of Frets: 22
- Truss Rod: EVH®-Branded with Wheel
- String Nut: Graph Tech® TUSQ®
- Nut Width: 1.75" (44.45 mm)
- Nut Material: Graph Tech® TUSQ®

Body
- Body: Chambered mahogany body with a basswood centerblock
- Body Finish: Gloss Urethane
- Body Shape: SA-126
- Body Top: Quilt Maple
- Body Binding: 5-Ply
- Body Material: Chambered mahogany body with a basswood centerblock

Hardware
- Bridge: EVH® Harmonica
- Bridge Mounting: Secured
- Control Knobs: Skirted Black Plastic with Numbered Indicators
- Switch Tip: Black
- Hardware Finish: Chrome
- Tuning Machines: EVH® Keystone Tuners
- Strings: Nickel Plated Steel (.009-.046 Gauges)
- Strap Buttons: Oversized

Electronics
- Bridge Pickup: EVH® SA-126 Humbucking
- Neck Pickup: EVH® SA-126 Humbucking
- Pickup Configuration: HH
- Controls: Volume 1. (Neck Pickup), Tone 1. (Neck Pickup), Volume 2. (Bridge Pickup), Tone 2. (Bridge Pickup)
- Switching: 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge And Neck Pickups, Position 3. Neck Pickup
- Potentiometers: 500k (Volume), 250k (Tone)

Measurements
- Dimensions: 8.00x20.90x47.00 IN
- Shipping Weight: 25.50 LB
- Upper Bout: 11" (27.94 cm)
- Lower Bout: 15.25" (38.73 cm)
- Body Depth: 1.75" (4.45 cm)
- Fret Size: Jumbo
- Scale Length: 24.75" (629 mm)
- Shipping Length: 47.00 IN
- Shipping Height: 8.00 IN
- Shipping Width: 20.90 IN

Miscellaneous
- Style: 2 Humbucking
