Jackson X Series Signature Adrian Smith SDXM Electric Guitar. Maple FB, Snow White with Black Pickguard

Iron Maiden is one of the most successful and influential metal bands ever, and Adrian Smith’s molten yet melodic guitar work has long been a driving force behind their distinctive and dynamic sound. With timeless songwriting and thrilling live performances, Maiden continues to record, tour internationally and rock stadiums everywhere with electrifying prowess and unwavering heavy metal passion.

Jackson pays tribute to the legendary axeman with the X Series Signature Adrian Smith SDXM model. Offered in an affordable price range, the SDXM features a basswood San Dimas® body and a bolt-on maple neck with graphite-reinforcement rods that refuse to budge, no matter how much environmental stress it’s exposed to. Its 12”-16” compound radius maple fingerboard with 22 jumbo frets and black dot inlays is the perfect launching pad for rapid-fire riffing or complex chords.

The SDXM packs a Jackson high-output humbucker in the bridge position and Jackson single-coil pickups in the neck and middle positions. The humbucking pickup was painstakingly voiced for full, rich tone while providing maximum overdrive and sustain, whereas the single-coil middle and neck pickups deliver that unmistakable Strat® snap. A five-way blade selector switch with single volume and tone controls open up endless tonal possibilities, while the Floyd Rose® Special double-locking tremolo system keeps the guitar in tune through any and all abuse you throw its way.

Specs:

Body: Basswood

Body Finish: Gloss

Control Knobs: Dome-Style

Fingerboard: Maple

Hardware Finish: Black

Neck Finish: Satin

Pickguard: 1-Ply Black

Inlays: Black Dot

Body Shape: San Dimas

Neck Material: Maple

Scale Length: 25.5" (648mm)

Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)

Number of Frets: 22

Fret Size: Jumbo

Nut: Floyd Rose® Locking

Nut Width: 1.6875" (42.86 mm)

Truss Rod: Dual-Action

Truss Rod Wrench: Yes

Bridge Pickup: Jackson® High-Output Humbucking

Middle Pickup: Jackson® Single-Coil

Neck Pickup: Jackson® Single-Coil

Controls: Volume, Tone

Pickup Switch: 5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup

Pickup Configuration: HSS

Bridge: Floyd Rose® Special Double-Locking Tremolo (Recessed)

Tuning Machines: Jackson® Sealed Die-Cast

Strings: Nickel Plated Steel (.009-.042 Gauges)
