Shure ANI4OUT-XLR 4-Output, XLR connectors, Mic/Line Dante Audio Network Interface with PEQ and Audio Summing

The Shure ANI4OUT-XLR is a compact audio network interface that converts up to four Dante™ digital audio channels into discrete analog outputs via XLR connectors. Designed for seamless integration into conference rooms, AV systems, and networked installations, the ANI4OUT-XLR offers robust signal processing, flexible routing, and remote browser-based control—all in a space-saving 1/3 rack chassis.dio signal to four discrete line / mic analog signals for easy audio routing and convenient browser-based remote control.

Converts Dante™ digital audio signal to four discrete line / mic analog signals.

Features

• Single Ethernet port carries Dante audio, power (PoE – class 0)
• LEDs indicate device status and audio signal
• Control strings for third-party preset controllers including
• Crestron® and AMX®
• 4 Band C/S PEQ on every channel
• Provides channel summing to combine Dante™ signals from the network and send them over a single analog output
• Browser-based software control for all device parameters, per output channel:
• Mute control

  • Digital gain
  • Polarity control
  • 1/3 Rack unit wide

Specifications

Audio Outputs
- Output Channels: 4 analog outputs
- Connector Type: XLR (balanced)
- Output Type: Line or mic level (selectable)
- Signal Routing & Processing
- Summing: Yes, channel summing from multiple Dante channels
- EQ: 4-band parametric EQ per output

Control Functions:
- Mute
- Digital gain adjustment
- Polarity inversion

Connectivity
- Network Port: 1x RJ45 (Dante-enabled, Gigabit Ethernet)
- Power: PoE (IEEE 802.3af Class 0)
- Control & Integration
- Interface: Browser-based UI
- Third-Party Support: Compatible with AMX®, Crestron®
- Software: Works with Shure Designer and Web UI

Construction
- Form Factor: 1/3 rack unit
- Mounting: Surface mountable or rack mountable (with optional hardware)
