Shure PA805X Passive Directional Antenna (944-952 MHz)

Directional antenna for increased range and reduced interference as compared to omnidirectional 1/2-wave antennas.

The Shure PA805 is a directional antenna for increased range and reduced interference as compared to omnidirectional 1/2-wave antennas.

The PA805 can be mounted on a microphone stand or mounted to a wall using the integral swivel adapter bracket.

In the Box
- 1 95L2035 Cable (10 ft BNC)

Specifications:

- Frequency Range: 944-952 MHz
- Antenna Gain: 6dBi Typical
- Radiation Pattern: directional; cardioid
- Connector: 50 W, Female, BNC-type
- Swivel Adapter: Positive-action, break resistant, adjustable from 0 to 90 degrees, with standard 5/8 in. -27 thread
- Dimensions: 226 mm H X 234 mm W X 40.6 mm D (8.9 in. H X 9.21 in. W X 1.60 in. D)
- Net Weight: 8 oz (227 grams)
