Vox Continental 73-Key Performance Synthesizer Organ TGF11

NEW OPEN BOX WITH WARRANTY

WE ARE AN AUTHORIZED KORG DEALER

SUPER FAST AND FREE SAME DAY SHIPPING

Intuitive user interface that emphasizes playability on stage

ORGAN part that meticulously models three vintage organs

High-quality E.PIANO part with attention paid to every detail

Rich PIANO part powered by high-capacity samples

The original VOX Continental, a transistor organ that appeared in the 1960s, is a timeless classic beloved by top players as a practical keyboard with a home on any live stage. Now, a completely new keyboard that carries this concept into the present day has been again released by the VOX brand. The VOX Continental uses a simple and intuitive interface that allows quick accessibility of every function. The high-quality sound engine section is centered on organ, electric piano, and acoustic piano, and provides a wealth of stage-ready sounds. In addition, the Continental features a powerful effects section to enhance these sounds, and even analog valve drive powered by Nutube, the cutting-edge vacuum tube. It's an instrument that perfectly fits your live performance requirements for a variety of styles including rock, pop, jazz, and more. The air of tradition that emanates from VOX organs, together with the innovation of decades of research, down to the illuminated VOX logo shows the new VOX Continental is a fusion of both, redefining the existence of the modern stage keyboard.

Keyboard: Semi-weighted waterfall (velocity sensitive is supported, after touch is not supported)

61 keys: C2 ? C7 (transposable in the range of [C0...C5] ? [C4...C9]), velocity sensitive C2 to C7

73 keys: E1 ? E7 (transposable in the range of [E-1...C5] ? [E3...E9]), velocity sensitive E1 to E7

Sound Generator

Maximum Polyphony:

Modeling tonewheel organ sound generator: 128 voices

Modeling transistor organ sound generator: 100 voices

Modeling electric piano sound generator: 80 voices

High-definition Piano sound generator: 60 dual stereo notes (equivalent to 240 voices max)

Modeling analog synthesizer sound generator: 36voices

PCM sound generator: 64 stereo notes (equivalent to 128 voices max)

- Actual maximum polyphony will vary depending on oscillator settings such as stereo multisamples and velocity crossfade.

PCM Memory: Approx. 10.5 GB (in case of 48 kHz, 16-bit Linear PCM converted)

ORGAN Part: 3 types (CX-3, VOX, COMPACT), Draw bar, Percussion ON/OFF, Split function, Vibrato/Chorus ON/OFF, Rotary Speaker ON/OFF)

E.PIANO Part: 3 types (TINE, REED, FM)

PIANO Part: 3 types (GRAND, UPRIGHT, E.GRAND)

KEY/LAYER Part: 6 types (KEY, BRASS, STRINGS, LEAD, SYNTH, OTHER)

Preset variations: 150

Scene: 16 (4 x 4), It is available to save 100 sets to external USB

Effects

Insert Effects: EFFECT: CHORUS, PHASER, FLANGER, COMP, DRIVE, WAH (control via pedal)

Master Effects:

DELAY: 1. DELAY, 2. CROSS, 3. TAPE, 4. MOD DLY

REVERB: 1. HALL1, 2. HALL2, 3. ROOM1, 4. ROOM2, 5. SPRING

EQ: 9-band stereo input/output

VALVE DRIVE: Vacuum tube Nutube 6P1

DYNAMICS: Control the amount of change in volume and tone produced by your keyboard playing dynamics

Controllers

Bend Lever:

ORGAN: Rotary Slow/Fast

E.PIANO: Tremolo ON/OFF

KEY/LAYER: Pitch bend

Touch sensors (electrostatic capacitance type):

ORGAN: Drawbars

KEY/LAYER: Sound controls

EQ: 9 band equalizer

Audio Characteristics

Frequency Characteristics: 20Hz ? 22kHz ±1.0dB 10k ? load

THD+N: 20Hz ? 22 kHz 0.005% (standard) 10k ? load

S/N Ratio: 105dB (standard)

Audio Output

OUTPUT L/MONO, R:

Connector: 6.3 mm (1/4") monaural phone jack, unbalanced

Output impedance: 1.1 ? (when outputting in stereo), 600 ? (L/Mono jack, when outputting in mono)

Maximum level: +16.0 dBu

Load impedance: 10k ? or more

OUTPUT L, R:

Connector: XLR-3-32 type (balanced) + LIFT - GND switch

Output impedance: 350 [?] (when outputting in stereo)

Maximum level: +16.0 [dBu]

Load impedance: 10k ? or more

HEADPHONES:

Connector: 6.3 mm (1/4") stereo phone jack

Output impedance: 50 ?

Maximum level: 150 + 150 mW @32 ?

Control Inputs

DAMPER: KORG DS-1H damper pedal (supports half-damper), PS-1 and PS-3 pedal switches

ROTOR SPEED: KORG PS-1 and PS-3 pedal switches

Other Sounds

MIDI: IN, OUT

USB: USB A (TYPE A): Saving/loading scene data, USB B (TYPE B): MIDI interfaces: 1 (16 ch) in/1 (16 ch) out, Complies with USB specification Ver. 2.0, High speed (up to 480 Mbps)

Main Specifications

Power: AC adapter connector (DC 15 V), power button

Dimensions (W x D x H):

61-key model: 36.97" × 13.78" × 3.39"

73-key model: 43.43" × 13.78" × 3.39"

Weight:

61-key model: 15.87 lbs

73-key model: 18.52 lbs

Power Consumption: 16W
