Yamaha StagePas 1K MKII Portable PA System, 1100W

$1,449.99
In stock
SKU
YAM-STAGEPAS 1K MKII

Brand New. Not available for curbside pickup. Online orders only.

Yamaha STAGEPAS 1K mkII All-in-One Portable PA System
The Yamaha STAGEPAS 1K mkII is a professional, all-in-one portable PA system that lets you transform any space into your stage. With 1100 watts of power, a 12" subwoofer, and a 10-speaker line array, this system delivers impressive clarity and coverage. Built-in Bluetooth, digital effects, and one-knob EQ controls make setup and sound shaping effortless—perfect for performers who want power, portability, and pro-level sound without the hassle.

Features

  • 1100W Class-D amplifier with 12" subwoofer and 10 x 1.5" line array speakers
  • 5-channel digital mixer with Bluetooth audio streaming
  • 1-knob EQ and MODE presets for quick sound tailoring
  • SPX digital reverb with 4 selectable programs
  • Monitor and Link outputs for expanded setups
  • Control via STAGEPAS Controller app (iOS/Android)
  • Ultra-portable with included carry cover and optional dolly

Specifications

General
- Type: Powered subwoofer with line array speaker
- Speaker Type: Bass-reflex subwoofer, enclosed line array
- Frequency Range (-10dB): 37 Hz – 20 kHz
- Coverage Area: Horizontal 170° / Vertical 30°
- Crossover: 240 Hz
- Maximum Output (1m, on axis): 125 dB SPL

Mixer
- Mixing Channels: 5 (Mono x3 + Stereo x1)
- Input Channel Functions: Hi-Z (CH2/3), 1-knob EQ (CH1-3/ST)
- Output Channel Functions: MODE (SPEECH / MUSIC / CLUB)

Inputs/Outputs
- Inputs: 3 x Mono (Mic/Line), 1 x Stereo (Line), 2 x Mono (Line), 1 x Link In
- Outputs: 1 x Link Out, 1 x Monitor Out
- Bluetooth: Version 5.0, A2DP (SBC, AAC)

Onboard Processing
- DSP: SPX Digital Reverb (4 programs with parameter control)
- Control Options: Reverb footswitch, STAGEPAS Controller app

Power
- Amplifier Class: Class-D
- Power Rating (Dynamic): 1100W
- Power Consumption: 25W (Idle), 91W (1/8 power)
- Power Requirements: 100V–240V, 50/60Hz (varies by region)

Physical
- Handle: 1 x Top of subwoofer
- System Dimensions (W x H x D): 13.15" x 78.74" x 16.46"
- Subwoofer Dimensions: 13.15" x 21.65" x 16.46"
- Line Array Dimensions: 2.64" x 22.91" x 3.39"
- Spacer Dimensions (each): 2.64" x 21.85" x 3.39"
- Weight (System): 50.7 lbs
- Weight (Subwoofer): 44.1 lbs
- Weight (Line Array): 4.0 lbs
- Weight (Spacers): 1.3 lbs each

Included Accessories
- Power Cord x1
- Cover x1
